Mimaki Laminator LA-160W

Mimaki Laminator LA-160W
Mimaki Laminator LA-160W
Mimaki Laminator LA-160W
Mimaki Laminator LA-160W
Mimaki Laminator LA-160W
Mimaki Laminator LA-160W
(Click to see larger image and other views)
SKU: LA-160W
Mimaki LA-160W laminator is a reliable and cost-effective solution for achieving professional-grade lamination results.
Brand: Mimaki
Price: $7,072.00
Product Details

Mimaki LA-160W is a high-quality hot-cold laminator machine that can meet all your professional needs. This top-of-the-line Mimaki vinyl laminator provides a range of advanced features that make it the perfect choice for any business looking to produce high-quality laminated prints.

The Mimaki LA-160W laminator is the ultimate solution for any business looking for a fast, easy-to-use, and highly versatile laminator. With a 62.2" maximum width, it can accommodate various materials and applications. Its fast throughput speeds and intuitive controls make it easy to operate and produce high-quality laminated prints in no time. The laminator machine also features easy access to the pressure handle and foot pedal and a convenient take-up reel that makes it easy for one person to operate the entire process, making it an ideal choice for any business looking to streamline their workflow. LA-160W is the best laminator to pair with a Mimaki printer.

With its advanced heating system and temperature controls, the LA-160W Mimaki laminator ensures a perfect finish whenever laminating film. This heat assist laminator improves laminate film adhesion, particularly to surfaces printed with UV ink, and reduces the potential for the silvering effect created by pressure-sensitive overlaminates. It can handle a range of materials, making it ideal for numerous applications. And with its rugged construction and durable components, it's built to last for years of reliable service.

Investing in a professional laminator is a great choice for any business looking to improve the quality and durability of its printed materials. A roll laminator is a versatile and efficient tool that can help you quickly laminate large volumes of prints, helping you simplify your graphics process.

So, if you're looking for a top-quality large laminating machine to help you take your business to the next level, look no further than the Mimaki LA-160W!

Price listed for machine only.  Call us for a quote on machine, installation, freight, basic training and to verify you are in our service area.

Maximum Processing Width

62.2" (1,580 mm)

Roller Diameter

4.72" (120 mm)

Processing Thickness

1.38" (35 mm max.)

Warming Temperature

140°F (60°C)

Processing Speed

0 to 295.3" min (0 to 7500 mm/min)

Core Diameter

3 inch


USA: 120V | EU: 230V | other: 100V

Rated Current

USA: 14A | EU: 8A | other: 15A

Power Consumption

1800W or less

Preheating Time

About 30 minutes

Pedal Switch


Attachment Shaft (with measure scale)

3" x 5 pcs.

Dimensions (W x D x H)

78.7" x 21.7" x 50.4" (2,000 x 550 x 1,280 mm)


451.9 lbs. (205 kg)
